MapleSim 4.5 Offers Modelica Import Capabilities

By DE Editors

Maplesoft’sMapleSim 4.5 is the latest version of the physical modeling and simulation tool. Available from Adept Scientific, MapleSimis an engineering software tool for design,  modeling and simulation, including real-time and hardware-in-the-loop applications.

The latest release includes enhanced support for Modelica,  an open standard for describing physical models and components that forms the basis of many components in MapleSim. With MapleSim 4.5, engineers can now access new collections of components using the Modelica import feature,  including third-party Modelica libraries and their own custom Modelica components in their MapleSim models.  Libraries, components and models based on the electrical, 1-D mechanical, signals and thermal heat flow domains from the Modelica 3.1 Standard Library can be easily imported into MapleSim and included with standard MapleSim components and models. Other enhancements include the ability to convert older MapleSim models to use Modelica 3.1, the latest version of the Modelica Standard Library.

MapleSim 4.5 includes an improved simulation engine that can simulate continuous models with discrete events. The enhanced engine handles a larger class of these systems than earlier versions and shows performance improvements for existing hybrid discrete/continuous models. With the improved engine MapleSim can now handle models that include hundreds of events. Models with discrete events will often run 10 times faster than in MapleSim 4, with some models running over 100 times faster, according to the company. The improved simulation engine also results in reduced formulation times for large continuous models, shortening the time the engine requires to prepare the model for simulation.

“With the expanded support for Modelica in MapleSim 4.5, and its increased capacity for modeling continuous systems with discrete events,  engineers and researchers can apply MapleSim’s time-saving techniques to even more of their design problems while educators can introduce students to an even wider variety of realistic examples,” says Laurent Bernardin, chief scientist and executive vice president of Research and Development at Maplesoft.  “MapleSim helps engineers deal effectively with the increasingly complex designs found in advanced engineering projects and helps students prepare to meet these challenges.”

For more information, visit Adept Scientific.

Sources: Press materials received from the company and additional information gleaned from the company’s website.
