GstarCAD 2011 Releases New Drawing Compare Function

Users can visualize differences between two DWG files.

Users can visualize differences between two DWG files.

By

By DE Editors

GstarCAD has published an enhanced function of GstarCAD 2011 called Drawing Compare. The tool is commonly used for comparing the differences between two DWG files after design modifications.


GstarCAD 2011 Releases New Drawing Compare Function

Drawing Compare can help quickly find out the distinctions between two CAD drawings. Modifications can be marked by various colors. Drawing Compare is also used with collaborative design. Designers from different fields can verify the changes and modifications of their own CAD drawings.

With GstarCAD 2011, Drawing Compare has been enhanced to test not only the modifications of the drawing objects,  but also modifications of block entity, block attribute, font style and dimension attribute. Test precision can be defined to ensure the accuracy of comparison result.

For more information, visit GstarCAD.

Sources:  Press materials received from the company and additional information gleaned from the company’s website.
