July 10, 2009
By DE Editors
CGTech is presenting the latest developments in composite fiber placement programming and simulation at the CompositesWorld Expo 2009. The presentation will be given by Bill Hasenjaeger, CGTech’s product marketing manager on Sept. 28. The CompositesWorld Expo 2009 show takes place September 28-30 at the Renaissance Schaumburg Hotel and Convention Center in Schaumburg, Ill.
Most users of CNC Automated Fiber Placement (AFP) machinery use off-line NC programming software delivered with their machine, forcing companies to adopt multiple software applications for multiple brands of machines. Hasenjaeger’s presentation will discuss the implementation and use of machine independent off-line NC programming software as it applies to CNC fiber placement machines.
“The more mature CNC metal-cutting industry started the same way, but has now evolved into a clear separation and cooperation between independent software and machine suppliers,” Hasenjaeger said. “This frees the company to select the best machine for the job, while using one software application to create NC programs for a variety of machine brands.”
During the exposition CGTech will be demonstrating VERICUT Composite Applications: VERICUT Composite Programming (VCP) and VERICUT Composite Simulation (VCS) in booth 300.
VCP reads CAD surfaces and ply boundary information and adds material to fill the plies according to user-specified manufacturing standards and requirements. Layup paths are linked together to form specific layup sequences and are output as NC programs for the automated layup machine.
VCS reads CAD models and NC programs, either from VCP or other composite layup path-generation applications, and simulates the sequence of NC programs on a virtual machine. Material is applied to the layup form via NC program instructions in a virtual CNC simulation environment. The simulated material applied to the form can be measured and inspected to ensure the NC program follows manufacturing standards and requirements. A report showing simulation results and statistical information can be automatically created.
CGTech will also be exhibiting the latest version of VERICUT CNC machine simulation and optimization software. VERICUT 7.0 features performance-improving enhancements that reduce the time required for manufacturing engineers to develop, analyze, inspect, and document the CNC programming and machining process. Instead of focusing on new features or add-on modules, CGTech developer resources have focused on diligent code optimization and customer-driven enhancements.
For more information, visit CGTech.
Sources: Press materials received from the company and additional information gleaned from the company’s website.
